Name: Ashley Fault Avoidance Overlay

Display Field: Name

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: While the Waimakariri District Council has taken all reasonable care in providing correct information, all information should be considered as being illustrative and indicative only. Your use of this information is entirely at your own risk. You should independently verify the accuracy of any information before taking any action in reliance upon it.Read the full disclaimer here.A full description is available in the Metadata.Abstract:Extent of the Ashley Fault Avoidance Zones. Areas of well-defined and distributed deformation have a 20 m buffer applied as per the Ministry for the Environment guidelines. Areas of uncertain and extended deformation were considered by the report authors to not have been mapped precisely enough to warrant assigning a 20 metre buffer. The joins between the well-defined and distributed deformation (with 20 m buffer) and the uncertain and extended deformation (without 20 m buffer) have been manually adjusted slightly to smooth out any sharp edges. The well-defined and distributed deformation areas (with 20 m buffer) have also been clipped out of adjacent uncertain or extended deformation areas.'Feature' is the type of ground deformation present.'FAZ_class' is the category of fault complexity, set out in Table 2 of the accompanying report, and following the MfE active fault guidelines.'NAME' is the fault or other landform unit that the deformation is associated with.'BUFF_DIST' is the width of the added buffer (20 m on well-defined or distributed deformation, 0 m on uncertain and extended deformation). Update Frequency:As needed.Point of Contact:Waimakariri District Council.Lineage:The data were captured at a scale of 1:5,000 to 1:10,000. Accuracy may vary.

Copyright Text: Created by Helen Jack, Environment Canterbury, April 2020 for the Waimakariri District Plan review. Based on mapping and data in Barrell, D. J. A.; Van Dissen, R. J. 2014. Assessment of active fault ground deformation hazards associated with the Ashley Fault Zone, Loburn, North Canterbury, GNS Science Consultancy Report 2013/173 / Environment Canterbury Report No. R14/77.

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1557080.0033999998
YMin: 5209089.8964
XMax: 1567677.1728999997
YMax: 5211187.0188
Spatial Reference: 2193  (2193)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [230, 0, 0, 255]
Outline:
Style: esriSLSSolid
Color: [110, 110, 110, 0]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: false
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Feature ( type: esriFieldTypeString, alias: Feature, length: 36 )
• FAZ_Class ( type: esriFieldTypeString, alias: FAZ_Class, length: 36 )
• Name ( type: esriFieldTypeString, alias: Name, length: 36 )
• BUFF_DIST ( type: esriFieldTypeDouble, alias: BUFF_DIST )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape_Length ( type: esriFieldTypeDouble, alias: Shape_Length )
• Shape_Area ( type: esriFieldTypeDouble, alias: Shape_Area )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
