Name: Rangiora Airfield Take Off Climb and Approach Obstacle Limitation Surface

Display Field: OBJECTID

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: While the Waimakariri District Council has taken all reasonable care in providing correct information, all information should be considered as being illustrative and indicative only. Your use of this information is entirely at your own risk. You should independently verify the accuracy of any information before taking any action in reliance upon it.Read the full disclaimer here.A full description is available in the Metadata.Abstract: The Civil Aviation Authority (CAA) Advisory Circular AC139-7 & AC91-15 addresses Aerodrome Standards and Requirements— Aeroplanes at or below 5700 kg MCTOW–Non Air Transport Operations (18 December 2009)While the aerodrome current exists and meets CAA standards of particular relevance to the PPC is the change to the Take-off climb/approach surface in clause 3.2.1 of the circular. This requires that each runway should have a takeoff climb and approach surface which should:(a) Rise from the end of the runway strip; and(b) Be obstacle free above a gradient of 1:20; and(c) Extend horizontally 1200 m from the inner edge; and(d) Have sides that are splayed outwards at the rate of 1:20; and(e) Not turn before 300 m from the inner edge, if a turn is necessary.Update Frequency: As required.Point of Contact:Waimakariri District CouncilLineage:Data was digitized using aerial imagery and LINZ parcel data. Accuracy may vary.
