Name: Coastal Marine Area Boundary

Display Field: OBJECTID

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: While the Waimakariri District Council has taken all reasonable care in providing correct information, all information should be considered as being illustrative and indicative only. Your use of this information is entirely at your own risk. You should independently verify the accuracy of any information before taking any action in reliance upon it.Read the full disclaimer here.A full description is available in the Metadata.Abstract:Coastal Marine Area Landward boundary within the Canterbury Region as shown in the Canterbury Regional Coastal Environment Plan 2005. The Coastal Marine Area Boundary (CMA) along the line of Mean High Water Springs (MHWS) and where it coincides with a river or stream, a distance of either one kilometre upstream from the mouth or a distance equivalent to five times the mouth of the river upstream.,MHWS has not been surveyed on the Canterbury coast. Therefore, this indicative line cannot be used as a legally defined line due to the margin of error involved. In the event of any dispute as to the precise location of the line of MHWS Environment Canterbury undertakes to establish the line for that specific area.Update Frequency:As needed.Point of Contact:Waimakariri District Council.Lineage:The areas in this Schedule are defined through the use of New Zealand Map Series grid referencesdelineating the boundaries of the relevant area within the Coastal Marine Area. The grid references are givento the nearest 100 metres. In some cases these grid references do not provide sufficient accuracy to exactlydesignate the area. This is because the line defining the boundary of the area may not start or end at a gridreference on shore exactly at the boundary of the Coastal Marine Area. Where the line crosses the CoastalMarine Area boundary the area is fully defined. However, where the line defining the boundary of an areafalls short of the boundary of the Coastal Marine Area, the relevant grid reference shall be interpreted asbeing the nearest point at the boundary of the Coastal Marine Area.

Copyright Text: Environment Canterbury.

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1574383.9357000003
YMin: 5195765.7489
XMax: 1578395.9028000003
YMax: 5211811.1257
Spatial Reference: 2193  (2193)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSDash
Color: [0, 92, 230, 255]
Width: 2
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: false
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID_1 ( type: esriFieldTypeOID, alias: OBJECTID_1 )
• OBJECTID ( type: esriFieldTypeSmallInteger, alias: OBJECTID )
• CODE ( type: esriFieldTypeString, alias: CODE, length: 3 )
• Label ( type: esriFieldTypeString, alias: Label, length: 36 )
• Descriptio ( type: esriFieldTypeString, alias: Descriptio, length: 107 )
• LENGTH_M ( type: esriFieldTypeDouble, alias: LENGTH_M )
• SOURCECODE ( type: esriFieldTypeString, alias: SOURCECODE, length: 6 )
• QARCODE ( type: esriFieldTypeSmallInteger, alias: QARCODE )
• CREATEDBY ( type: esriFieldTypeString, alias: CREATEDBY, length: 22 )
• CREATEDDAT ( type: esriFieldTypeDate, alias: CREATEDDAT, length: 8 )
• MODIFIEDBY ( type: esriFieldTypeString, alias: MODIFIEDBY, length: 22 )
• MODIFIEDDA ( type: esriFieldTypeDate, alias: MODIFIEDDA, length: 8 )
• Shape_Leng ( type: esriFieldTypeDouble, alias: Shape_Leng )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape_Length ( type: esriFieldTypeDouble, alias: Shape_Length )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
